Description

Percent Oxygen Analyzer in NEMA Enclosure – AII GPR-2500

For General Purpose and Hazardous Areas



AII GPR-2500 Percent Oxygen Analyzer is for percentage oxygen measurements in both general purpose or hazardous areas. Available in several variants, all of which are supplied in a lightweight NEMA enclosure with stainless steel wetted parts and easy to access electrochemical oxygen sensors for user-friendly maintenance.



AII GPR-2500 Percent Oxygen Analyzer Features

  • Advanced galvanic electrochemical sensors
  • Measuring oxygen in ranges: 0-1% up to 0-100% (model dependant)
  • Auto-ranging or fixed range (user selectable)
  • Long lifespan of the GPR sensor of 32 months and more
  • Simple to use HMI



Oxygen analyzers and sensors for industrial gas:

Simple to use, and providing best-in-class reliability in demanding industrial environments, our oxygen analyzers are available as fixed installation or as portable instruments for spot-checking processes.



Model & range:

GPR-2500N (ATEX) GPR-2500A GPR-2500MON GPR-2500AMO
Measurement range 0-1%, 0-5%, 0-10%, 0-25% 0-1%, 0-5%, 0-10%, 0-25% 0-100% 0-100%
Accuracy

< 2% of range at constant conditions

Response time T90 < 10 seconds T90 < 10 seconds T90 < 13 seconds T90 < 13 seconds
Sensitivity (LDL)

< 0.5% of scale



Linearity

<1% of scale

Sensor model GPR-11-32-4
XLT-11-24-4 for gases containing > 0.5% CO2
GPR-11-32-4
XLT-11-24-4 for gases containing > 0.5% CO2
GPR-11-120-4 GPR-11-120-4
Sensor life in air at 25°C (77°F) and 1 atm GPR-11-32-4: 32 months
XLT-11-24-4: 24 months
GPR-11-32-4: 32 months
XLT-11-24-4: 24 months
GPR-11-120-4: 24 months in 100% O2
Calibration interval

30 days

Inlet pressure

0.34-2 barg (5-30 psig) with atmospheric vent

Flow rate

0.5-1.0 l/m (1-2 SCFH)

Gas connections

1/8″ compression tube fittings

Wetted parts

Stainless steel

Display Graphical LCD 7 x 3.5cm (2.75 x 1.375”); resolution 0.001% Graphical LCD 7 x 3.5cm (2.75 x 1.375”); resolution 0.001% Graphical LCD 7 x 3.5cm (2.75 x 1.375”); resolution 0.1% Graphical LCD 7 x 3.5cm (2.75 x 1.375”); resolution 0.1%
Enclosure

Fiberglass NEMA 4X, 10.1 x 22.9 x 7.6cm (4 x 9 x 3″)

Weight

3.6kg (8lbs)

Compensation Temperature Barometric pressure and temperature Temperature Barometric pressure and temperature
Signal output

4-20 mA

Alarms N/A Two user configurable alarms: magnetic coil relays rated 3A at 100 V AC N/A Two user configurable alarms: magnetic coil relays rated 3A at 100 V AC
Operating temperature

GPR sensor: 5°C to 45°C (41°F to 113°F)
XLT sensor: -10° to 45°C (14°F to 113°F)

Power 18-24 V DC 12-28V DC non-loop or 110-220 V AC 18-24 V DC 12-28 V DC non-loop or 110-220 V AC
Area Classification II 2 G
Ex ia IIB T4 Gb
Tamb -20°C to +50°C

Additional information

Model

GPR-2500 N (ATEX), GPR-2500 A, GPR-2500 MON, GPR-2500 AMO
