SAFEGAS SKY3000-SP Gas Detector

RM 0.00

SKU: SKY3000-SP Categories: , , , , , , Tags: , ,

Description

SKY3000-SP Gas Detector



The SAFEGAS SKY3000-SP Gas Detector offers for leak testing, and confined space entry. SAFEGAS SKY3000-SP Gas Detector have bright LED alarm lights. It will be use for for leak testing, and confined space entry.



Features:

  • Optional measures up to 4 gases, (O2, CH4, CO, H2S)
  • Gas leak detection measures methane in three different distinct ranges (ppm / LEL / %Volume). Auto ranging between all three ranges, audible, visual, and gieger alarms, and ergonomical design allows for easy one-handed operation.
  • With flexible probe for testing undrerground leaks, measures gas beginning in the LEL range and autoranges to % Volume. Barhole probe included with instrument.
  • Rugged polycarbonate case, sealed to IP67
  • One press to restore factory settings
  • Large graphical display can rotate 180°
  • Low power consumption, long stand by time
  • Support firmware upgrade remotely



Specifications:

Gas Detected O2、CO、H2S、CH4 is the standard gas combine, other combine can be specified.
Detection Principle Electrochemical (O2, CO, H2S),?Catalytic combustion (LEL)?
Measure range CO: 0-1000ppm, H2S: 0-100ppm, O2: 0-30%VOL,
CH4: 0-10000ppm, 0-100%LEL, 0-100%VOL
Resolution Specified according to application.
Response time ≤30 seconds
Precision ≤±1-5% F.S except for special gases
Language Chinese/English/Polish (More language can be customized)
Automatically test and calibrate after power-on Including reset, maximum value (MAX), minimum value (MIN), STEL, TWA value
Unit PPM, mg/m3, %LEL, % VOL
Display LCD (160 x96) ,180° rotate.
Backlight Turned on automatically when alarming, the backlight time can be manually set.
Data record 100,000 readings, the storage interval is adjustable from 5 to 3600 seconds, data can be exported to P C no need software.
Alarm 95dB@30cm buzzer alarm, flashing red LED alarm and vibration al arm.
Battery 3.7V rechargeable lithium battery, battery capacity 2200mA
Working hours More than 15 hours in continuous pumping mode
Charger Travel charger with DC interface, charging time ≥ 4 hours.
Explosion-proof grade IECEX/ATEX（II IG Ex ia IIC T4CNEX: Ex ia IIC T4 Ga
Certification(EU regulations) 2004/108/EC（EMC）
2004/34/UE (ATEX）（ATEX）CE
Protection grade IP67
Working temperature -20℃~+50℃
Humidity 10～90%RH（no condensation）
Environmental pressure 86～106Kpa
Size 157*84.5*59.5mm
Weight 365g (including battery, belt clip and filter)



Gas & ranges:

Detected gas Range Resolution
Oxygen（O2） 0-25%/0-30%VOL 0.1%VOL
Carbon monoxide CO） 0-1000/0-2000ppm 1ppm
Hydrogen sulfide（H2S） 0-100ppm 1ppm
Methane（CH4） 0-10,000ppm 1ppm
Methane（CH4） 0-100% LEL 1%LEL
Methane（CH4） 0-100% Volume 1%LEL
